Slalom by CUF Milano

Maneuvrable and light low partition, composed by curved modules connected each other.

• Slalom is a modular divider system with 4-way satin-finished aluminium uprights at 90°.
• Panels can be made of fire-retardant PVC, painted metal, microperforated and ECO (recycled and recyclable fibre panels).
• Thanks to its wide range of colours and materials, each space can be designed and created in a unique and personal way.
• Supporting element consisting of:
• disc base diameter mm. 244 x thickness mm. 6 in oven-fired steel painted with epoxy powders in embossed grey and embossed black, complete with mats on the floor.
• Cylinder fixing column diameter mm. 75 x h. mm.  120 in oven-fired steel painted with epoxy powders in embossed grey and embossed black.
• extruded tubular profile in satin-finished aluminium alloy and natural/black anodized, diameter mm. 32 x h. 1168/1446/1724/2002 with M6 threaded ends designed for attachment to the base and top finishing element.
• top finishing element with upper finishing element external diameter mm. 35 x h. 17 in oven-fired steel painted with epoxy powders in embossed grey and embossed black.
• Galvanised steel lower spacer, diameter mm. 42 x h. 3
• Panels: Microperforated sheet metal panel flexible at 20°, thickness mm. 0.5 painted with epoxy powders in embossed grey and embossed black.
• Flexible 3° solid sheet metal panels, thickness mm. 0.6 painted with epoxy powders in embossed grey and embossed black.
• Self-extinguishing PVC panels, 360° flexible, thickness mm. 0.7, in transparent, white, grey, opaline and smoked finishes, with stitch textures, stripes, paintings, optical, mosaic and digital print textures.
• ECOfriendly ECOwood self-extinguishing, 360° flexible, thickness mm. 1.4 recycled and recyclable fibres, in finishes with ecological ink based on cherry water, maple bleached, grey, pink green, wenge and cork.
• ECOpanel self-extinguishing, 360° flexible, thickness mm. 1.4 recycled and recyclable fibres, in finishes with eco-friendly water-based solid ink or textures.
• ECOtex self-extinguishing, 360° flexible, thickness mm. 1.4, recycled and recyclable fibre core, ECO fabric coating in eco-friendly water-based solid ink or textures.
• ECOfriendly and FON-absorbents
• ECOflex self-extinguishing, 360° flexible, thickness mm. 30, Recyclable and embroidered fibre lining, Trevira CS fabric finish
• ECOstrong self-extinguishing, rigid, thickness mm. 30, Recyclable and embroidered fibre lining, Trevira CS fabric finish
